Model:

  • SP-525M

  • SP-525MS

  • SP-525T

  • SP-525TS

OVERVIEW:

SPINDLE SHAPER SERIES - 525 SERIES

Description



A dependable source for all your needs in high quality spindle shapers

TILTING SPINDLE



  • The tilting spindle provides angle cutting form -5°~90°~+45°. Spindle tilting handwheel is located at front within easy reach. A tilt scale is attached for accurated angle setting.

SLIDING TABLE ( MODELS SP-525MS, SP-525TS, SP-625MS AND SP-625TS ONLY )



  • Sliding table model is an integrated system providing maximum accuracy and effortless cutting effects. Sliding table is integrated with (6) nsk#6004 accentric roller bearings with accuracy to 0.002”. Tenoning attcachment is included as standard feature.

QUICK CHANGE SPINDLE SPEEDS



  • V-belt is quickly released for speed change by simply loosening one lock lever, and shifting the belt to required position.

FENCE



  • Cast aluminum alloy fence halves are precision machined. The fence assembly is attached with a 5” diameter outlet dust hood.

  • The fence halves can be precision adjusted by micrometric adjustment knob with 0.008” graduation.

INTERCHANGEABLE SPINDLES:



  • Choice of 3 spindle diameters (3/4”, 1”, 1-1/4”) or choice of metric sizes- 19mm, 25.4mm, 30mm. spindle has mk5 taper to ensure precision fitting and allow quick changeover.

QUICK CHANG SPINDLE SPEEDS:



  • The spindle is driven by a four-speed dynamically balanced pulley for spindle speeds of 3000, 4500, 7500 and 10000 r.p.m. change of speed is quick and easily accomplished by simply loosening a lock lever, and shifting the belt to the required speed setting.

REVERSIBLE SPINDLE ROTATION:



  • The spindle is reversible to ensure safe rotation in clockwise or counter-clockwise direction as well as providing the ability to climb cut glued panels.

SPINDLE RAISING:



  • The spindle is raised or lowered by a graduated handwheel, providing 1mm elevation per full revolution, quick clamp lever positively holds spindle at a set height.

TABLE INSERTS:



  • The spindle is fitted with 2 insert rings (6-3/8” & 8-5/8”) permitting for use of a wide variety of shaper cutters and spindle speeds.

FENCE:



  • The fence assembly is attached with a 4” diameter outlet dust hood. The fence halves can be prcision adjusted by micrometric adjustment knob with 0.008” graduation.

TABLE:



  • The massive table is made from hight quality cast iron (fc-25 grade) and undercast ribbing is engineered for maximum strength and long term table stability. Table surface is precision ground and polished.

ROUTING OPERATION:



  • The mk5 taper on the spindle accepts a router collet system, providing maximum flexibility all in one shaping and routing machine.

SPECIFICATION
